Condensate Atomization Pump P15J - flow rate 10 litres/hour with 2 nozzles, suitable for splits up to 30,000 BTU/hour (8.8 kW), built-in 35 ml tank.

Condensate Atomization Pump P15J - flow rate 10 litres/hour with 2 nozzles, suitable for splits up to 30,000 BTU/hour (8.8 kW), 35 ml tank.

P15J is for atomizing air conditioner condensate drainage.

The system consists of only a few elements to reduce the risk of malfunctions and failures.

A central apparatus (pump and diaphragm) protected by a white box, a tube to collect the discharge water, a small tube to dispose of the mist and an end nozzle that only need connecting together to solve the condensate drainage problem in a practical, fast and cost-effective way.

And Enhanced refrigeration effect of the system at the same time.

• Stop condensate water's dripping and free of condensate pipe's installation
• Increase the heat exchange efficiency by water evaporation absorbs a lot of heat
• Enhanced refrigeration effect of the system obviously, saving the energy

TECHNICAL SPECIFICATIONS:

• Power supply: 220 V 50 Hz
• Flow rate (max): 10 litres/hour with 2 nozzles
• Suitable for splits up to: 30.000 BTU/hour (8,8 kW)
• Pressure: 3 bar
• Suction lift (max): 1,5 mt.
• Tank capacity: 35 ml
• Sound level at 1 metre: 40-45 db(A)
• Power: 25 W
• Ambient temperature: 0-50 °C

Dimensions: 157x126x(d) 75 mm.
