MPS-series – Detectors for connection to MPU/SPU/SPLS with IR sensor (NDIR)
SAMON code: 34-410
Sensor for installation in engine rooms, compressor rooms and any other application where gases are used or stored.
The MP series sensors have been designed specifically for the MPU / SPU
Measuring ranges and alarm levels:
The alarm levels are always set on the control unit.
Appropriate measuring ranges and alarms depend on the environment in which the detectors are installed and the type of gas to be detected
Compliant with EN 378:2008
Features:
0-10,000 ppm
Requires connection to MPU2C, MPU4C, MPU6C and SPU control units
Selective IR (NDIR) measurement system, long life and stability
Power supply from the control unit
Waterproof and anti-corrosion housing for installation in industrial environments
Integrated heater for firgoriferi warehouses
Ambient temperature -40°C +50°C
Humidity 0-95% Rh (non-condensing)
IP67 protection
NOTE:
Sensors are consumable parts, estimated life 10 years. Automatic zero calibration. Simple replacement. Sample gas calibration method. Annual maintenance.
The alarm level is set on the control unit, usually during start-up
